| Model | JY-HMS SERIES | ||||||||||
| Function | Capacity(ml) | 50 | 100 | 250 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 | 20000 |
| Heating Mode | Surface heat-conduction | ||||||||||
| Surface Max. Temp.( ℃) | 450℃ | ||||||||||
| Speed range | 0～1600rpm | ||||||||||
| Structure | Heating element | Nichrome wire | |||||||||
| Stir bar | PTFE | ||||||||||
| Shell(Insulation Layer) | High quality aluminum silicate cotton | ||||||||||
| Motor power | 0.01kW | ||||||||||
| Heating power (kW) | 0.08 | 0.1 | 0.15 | 0.25 | 0.35 | 0.45 | 0.6 | 0.8 | 1.2 | 2.5 | |
| Controller | Working Mode | Continuous | |||||||||
| Specification | Exterior Size (mm) | ￠220×165 | ￠280×220 | ￠330×230 | ￠340×245 | ￠350×250 | ￠425×320 | ￠470×340 | |||
| Packing Size (mm) | 230×230×195 | 290×290×300 | 340×340×350 | 360×360×300 | 390×390×310 | 430×430×350 | 510×510×380 | ||||
| Voltage(V) | 100～120V or 200～240V | 200～240V | |||||||||
| N.W.(Kg) | 2.5 | 5.5 | 6.5 | 7.5 | 8 | 9.8 | 16 | ||||
| G.W. (Kg) | 2.8 | 6 | 7 | 8 | 9.2 | ||||||
